Ford Mustang Mach-E (2021-…) – fuse box
Ford Mustang Mach-E (2021-…) – fuse box diagram
Year of production: 2021.
Location of the fuse box
Body control module fuse box
The fuse box is located on the right-hand side in the passenger footwell.
Fuse box under the hood
The fuse box is on the right side of the engine compartment.
- Remove the boot lid.
- Pull the latch toward you and remove the top cover.
- Pull the connector lever up.
- Pull the connector upward to remove it.
- Pull both latches towards you and remove the fuse box.
- Turn over the fuse box and open the cover.
Installing and removing the boot lid
Rear trunk lid
- Start at the back edge of the left side.
- Pull up on the clamp locations shown to release the clamps.
- Remove the cover.
- To install, reverse the removal procedure.
Left / right luggage compartment covers
- Start at the back edge of the right (or left) page and work toward the front of the cover.
- Pull up on the clamp locations shown to release the clamps.
- Remove the cover.
- To install, reverse the removal procedure.
Fuse box diagrams
Body control module fuse box diagram
Fuse allocation in the BCM fuse box
| Number | Amperes [A] | Description |
|---|---|---|
| 1 | 5 A. | Not used. |
| 2 | 5 A. | Not used. |
| 3 | 10 A. | Extended power module. |
| 4 | 10 A. | Multifunction display. |
| 5 | 20 A. | Not used. |
| 6 | 10 A. | Not used. |
| 7 | 30 A. | Passenger door module. |
| 8 | 5 A. | Not used. |
| 9 | 5 A. | Automatically dimming exterior mirror. |
| 10 | 10 A. | Extended power module. |
| 11 | 5 A. | Electric loading hatch;Hands-free boot lid activation module;
Telematics control unit module. |
| 12 | 5 A. | Anti-theft alarm;Keyless keyboard switch;
Driver’s front door activation switch; Driver rear door activation switch. |
| 13 | 15 A. | Not used. |
| 14 | 30 A. | Driver door module. |
| 15 | 15 A. | Not used. |
| 16 | 15 A. | Active Suspension (GT). |
| 17 | 15 A. | SYNCH. |
| 18 | 7.5 amps | Wireless accessory charging module;Driver Health Monitor;
Passenger’s front door activation switch; Passenger rear door activation switch. |
| 19 | 7.5 amps | Headlight switch kit;Bluetooth module with low energy consumption;
Vehicle start button; |
| 20 | 10 A. | Burglar alarm. |
| 21 | 7.5 amps | CAN gateway module;Climate control;
Gear shift module; |
| 22 | 7.5 amps | Instrument cluster;Steering column control module. |
| 23 | 20 A. | Audio unit. |
| 24 | 20 A. | Not used. |
| 25 | 30 A CB | Not used. |
The scheme of the fuse box under the hood
Assignment of fuses in the fuse box under the hood
| Number | Amperes [A] | Description |
|---|---|---|
| 1 | – | Not used. |
| 2 | 40 A. | Not used (spare). |
| 3 | 15 A. | Windshield wiper heating. |
| 4 | 40 A. | Not used (spare). |
| 5 | – | Not used. |
| 6 | – | Not used. |
| 7 | – | Not used. |
| 8 | – | Not used. |
| 9 | – | Not used. |
| 10 | – | Not used. |
| 11 | 15 A. | Powertrain control module. |
| 12 | – | Not used. |
| 13 | 15 A. | Air conditioning electric compressor;Active grille shutter;
Powertrain control module heater cooling pump; Powertrain control module heater shutoff valve. |
| 14 | 15 A. | Secondary power unit (GT) transmission fluid pump. |
| 15 | – | Not used. |
| 16 | 10 A. | Battery charge control module |
| 17 | – | Not used. |
| 18 | 10 A. | Powertrain control module. |
| 19 | 10 A. | Braking system control module. |
| 20 | 5 A. | Charging port status indicator. |
| 21 | 5 A. | Front luggage compartment actuator relay coil. |
| 22 | 20 A. | Amplifier. |
| 23 | 20 A. | Electronic rear door on driver’s side. |
| 24 | – | Not used. |
| 25 | 25 A. | Reinforced left-hand headlights. |
| 26 | 25 A. | Right-hand headlights reinforced. |
| 27 | 5 A. | Keep the power alive. |
| 28 | 5 A. | Front luggage compartment actuator relay coil. |
| 29 | 5 A. | DC / DC converter. |
| 30 | – | Not used. |
| 31 | 5 A. | Electronic power steering. |
| 32 | 30 A. | Body control module. |
| 33 | 20 A. | Advanced driver assistance system. |
| 34 | 10 A. | Headlamp control module. |
| 35 | 15 A. | Heated steering wheel. |
| 36 | 10 A. | Hybrid powertrain master control module;Auxiliary power distribution box;
Auxiliary control module for hybrid powertrain. |
| 37 | 20 A. | Horn. |
| 38 | 40 A. | Blower motor. |
| 39 | – | Not used. |
| 40 | – | Not used. |
| 41 | 20 A. | Amplifier. |
| 42 | 30 A. | Electric driver’s seat. |
| 43 | 40 A. | Anti-lock braking system valves. |
| 44 | 60 A. | Auxiliary power distribution box. |
| 45 | 30 A. | Passenger electric seat. |
| 46 | – | Not used. |
| 47 | – | Not used. |
| 48 | – | Not used. |
| 49 | 60 A. | Anti-lock brake system pump. |
| 50 | 60 A. | Cooling fan. |
| 51 | – | Not used. |
| 52 | 5 A. | USB port. |
| 53 | – | Not used. |
| 54 | – | Not used. |
| 55 | 30 A. | Heated seats. |
| 56 | 20 A. | Front trunk module. |
| 57 | 10 A. | Data link connector. |
| 58 | – | Not used. |
| 59 | 40 A. | Body control module. |
| 60 | – | Not used. |
| 61 | 20 A. | Auxiliary power point. |
| 62 | – | Not used. |
| 63 | – | Not used. |
| 64 | 30 A. | Electric loading hatch. |
| 65 | 30 A. | Vehicle dynamics module. |
| 66 | – | Not used. |
| 67 | – | Not used. |
| 68 | 5 A. | Battery electronic control module. |
| 69 | 20 A. | Electronic rear door on passenger side. |
| 70 | – | Not used. |
| 71 | 20 A. | Auxiliary power point. |
| 72 | 20 A. | Rear window wiper. |
| 73 | – | Not used. |
| 74 | 30 A. | Windshield wiper motor. |
| 75 | – | Not used. |
| 76 | 30 A. | Heated rear window. |
| 77 | – | Not used. |
| 78 | 20 A. | Electronic front door on the driver’s side. |
| 79 | 20 A. | Electronic front door on passenger side. |
| 80 | – | Not used. |
| 81 | 10 A. | Rear window washer pump. |
| 82 | – | Not used. |
| 83 | – | Not used. |
| 84 | 40 A. | Not used (spare). |
| 85 | 5 A. | Rain sensor. |
| 86 | – | Not used. |
| 87 | – | Not used. |
| 88 | – | Not used. |
